Features:
- JBL 15 in low frequency driver with a 64 mm (2.5 in) diameter edgewound ribbon voice coil which provides more cross-sectional wire area in the voice coil gap than round wire designs, for greater efficiency and power handling.
- JBL 2414H-C 25 mm (1 in ) polymer diaphragm compression driver improves high frequency performance as well as system reliability.
- The advanced network topology crossover design shapes the frequency response to deliver coherent summation in the crossover region.
- High-voltage capacitors and inductors with massive cores and heavy gauge wire enable the crossover network to handle high power without saturating.
- Progressive Transition™ high frequency waveguide provides superior coverage control, reduced distortion, and smoother frequency response.
- The rugged, acoustically superior enclosure is constructed from 19 mm (.75 in ) MDF (Medium Density Fiberboard) using advanced adhesives and mechanical fastener technology for extreme durability and improved low-frequency performance.
- SonicGuard™ protects the high frequency driver from excess power without interrupting the performance.
- Non-resonant, all-steel handles are used.
- Attractive 18-gauge perforated, steel grille protects components from damage.
- Dual-angle pole-mount socket allows the speakers to tilt 10° for more uniform audience coverage.
مشخصات | توضیحات |
---|---|
آمپلی فایر | ندارد |
سایز ووفر | 15 اینچ |
سایز تویتر | 1 اینچ |
نهایت توان خروجی | 1000 وات |
خروجی | 1 x 1/4″ in parallel with 1 x speakon |
ورودی |
1 x 1/4″ in parallel with 1 x speakon
|
رنج پاسخ فرکانسی | 38Hz-16khz |
آمپدانس |
8 Ω
|
حداکثر SPL |
128 dB
|
جنس بدنه | 3/4″ MDF |
طول | 699 میلی متر |
عرض | 460 میلی متر |
ارتفاع | 432 میلی متر |
وزن | 27.4 کیلوگرم |
